petkit-bridge

Bring your PetKit feeders, litter boxes and fountains into Apple HomeKit via Homebridge — no official plugin required.

Local HTTP bridge for PetKit devices, designed for integration with Homebridge (generic HTTP plugins) and go2rtc (video via WHEP). It relies on the unofficial pypetkitapi library to talk to the PetKit cloud and exposes a small token-protected local API.

Using Homebridge? There is an official companion plugin: homebridge-petkit-bridge (npm). Install it from the Homebridge UI, point it at this bridge (URL + token) and your devices are auto-discovered as HomeKit accessories — no manual accessory configuration needed. This bridge itself is not a Homebridge plugin: it is the companion service the plugin (or any HTTP client) talks to. Prefer wiring things manually? Generic HTTP plugins (e.g. homebridge-http-switch) work too — ready-to-paste examples below.

Unofficial project, not affiliated with PetKit. Use at your own risk.

Why

Generic Homebridge plugins (HTTP switch/sensor) cannot talk to the PetKit cloud. This bridge acts as a translator: on one side it maintains the PetKit cloud session, on the other it exposes simple, stable HTTP endpoints on the local network.

The bridge is designed to be resilient to cloud session expiry: the PetKit session expires periodically and, without countermeasures, the service stops responding until you restart the container. Here instead:

• the background refresh detects the expired session and logs back in on its own, rebuilding the client and HTTP connection from scratch (equivalent to an internal restart);
• incoming HTTP requests that hit an expired session also trigger an on-the-fly re-login instead of failing;
• exponential backoff on generic network failures, to avoid hammering the cloud while it is unreachable;
• /healthz?strict=1 responds 503 when the session is not valid, so a Docker healthcheck can restart the container as a last-resort safety net;
• startup does not crash if the first login fails (e.g. network not ready yet at boot): it starts in a degraded state and keeps retrying.

Requirements

• A PetKit account dedicated to the bridge, different from the one used in the phone app. PetKit allows a single active session per account: if you share the account, every time you open the app the bridge gets logged out (and vice versa). Create a second account and share your devices with it from the main app.
• Docker with the compose plugin (recommended), or Python 3.11+ for direct execution.

Quick start

git clone https://github.com/raulhartzen/petkit-bridge.git
cd petkit-bridge
cp .env.example .env        # fill in credentials and token
cp docker-compose.example.yml docker-compose.yml
docker compose up -d --build
docker compose logs -f petkit-bridge

On a successful start you will see the login to the PetKit server and the discovery of your devices. Configuration happens exclusively via environment variables, documented one by one in .env.example.

API

All endpoints (except /healthz) require the token, passed as an Authorization: Bearer <token> header, an X-Auth-Token header, or the ?token= query string (the latter exists for go2rtc WHEP sources, which cannot send custom headers — avoid it elsewhere, since query strings end up in logs).

Method	Path	Description
GET	/healthz	Bridge status; with ?strict=1 responds 503 if the PetKit session is not valid
GET	/devices	List of discovered devices
GET	/device/{id}	Raw JSON dump of the device (useful to discover your model's fields) — redact serial numbers, MAC addresses and Wi-Fi fields before sharing dumps publicly (e.g. in GitHub issues)
GET	/device/{id}/state	Compact state (mapped for feeder d4h, litter box t4, fountain ctw3; other models: use the raw dump)
GET	/device/{id}/hk-state	State in the format expected by Homebridge HTTP plugins
GET	/device/{id}/events	Normalized event feed (litter visits with pet name/weight, feeder eat/feed sessions); ?since= and ?limit= supported
GET	/device/{id}/maint-status	Maintenance status
POST	/device/{id}/feed	Manual food dispensing
POST	/feed-all	Dispense on all feeders
POST	/device/{id}/clean	Start litter box cleaning
POST	/device/{id}/litter	Litter box commands
POST	/device/{id}/scoop	Scooping cycle
POST	/device/{id}/fountain	Fountain commands
POST/PATCH/DELETE	/device/{id}/whep	WHEP video sessions for go2rtc (SDP offer, trickle ICE, teardown)

Homebridge examples (manual setup)

The recommended way to use this bridge with Homebridge is the homebridge-petkit-bridge plugin, which auto-discovers everything. The examples below are the manual alternative using generic HTTP plugins — useful for custom setups or unsupported device types.

The examples below assume the bridge runs at http://192.168.1.10:8787 and were written for these devices: a Yumshare Solo feeder (type d4h), a Puramax 2 litter box (type t4) and an Eversweet Max fountain (type ctw3). First call GET /devices (with your token) to find your device IDs, then replace DEVICE_ID and YOUR_TOKEN in the snippets.

The command examples use the popular homebridge-http-switch plugin. Note: plugin config schemas evolve — if a snippet is rejected, check it against the plugin's own README for your installed version.

Feed button (Yumshare Solo / d4h) — a stateless switch that dispenses one portion when tapped:

{
  "accessory": "HTTP-SWITCH",
  "name": "Feed Cats",
  "switchType": "stateless",
  "onUrl": {
    "url": "http://192.168.1.10:8787/device/DEVICE_ID/feed",
    "method": "POST",
    "body": "{\"amount\": 1}",
    "headers": {
      "X-Auth-Token": "YOUR_TOKEN",
      "Content-Type": "application/json"
    }
  }
}

Litter cleaning button (Puramax 2 / t4) — starts a cleaning cycle:

{
  "accessory": "HTTP-SWITCH",
  "name": "Clean Litter Box",
  "switchType": "stateless",
  "onUrl": {
    "url": "http://192.168.1.10:8787/device/DEVICE_ID/clean",
    "method": "POST",
    "body": "{\"mode\": \"CLEANING\"}",
    "headers": {
      "X-Auth-Token": "YOUR_TOKEN",
      "Content-Type": "application/json"
    }
  }
}

A single timed scoop cycle (START, wait, END handled by the bridge) is also available via POST /device/DEVICE_ID/scoop with an optional body {"wait": 50} — same switch pattern as above.

Maintenance mode switch (Puramax 2 / t4) — a stateful switch that enters/exits maintenance and reflects the real state via maint-status (which returns plain-text 1/0):

{
  "accessory": "HTTP-SWITCH",
  "name": "Litter Maintenance",
  "switchType": "stateful",
  "onUrl": {
    "url": "http://192.168.1.10:8787/device/DEVICE_ID/litter",
    "method": "POST",
    "body": "{\"action\": \"START\", \"mode\": \"MAINTENANCE\"}",
    "headers": {
      "X-Auth-Token": "YOUR_TOKEN",
      "Content-Type": "application/json"
    }
  },
  "offUrl": {
    "url": "http://192.168.1.10:8787/device/DEVICE_ID/litter",
    "method": "POST",
    "body": "{\"action\": \"END\", \"mode\": \"MAINTENANCE\"}",
    "headers": {
      "X-Auth-Token": "YOUR_TOKEN",
      "Content-Type": "application/json"
    }
  },
  "statusUrl": {
    "url": "http://192.168.1.10:8787/device/DEVICE_ID/maint-status",
    "method": "GET",
    "headers": { "X-Auth-Token": "YOUR_TOKEN" }
  }
}

The exact action/mode combination to exit maintenance can vary by firmware; the /litter endpoint accepts any DeviceAction + LBCommand pair precisely so you can test combinations in the field (e.g. with curl) before wiring them into HomeKit.

Fountain sensors (Eversweet Max / ctw3) — GET /device/DEVICE_ID/hk-state returns a flat JSON designed for HTTP sensor plugins:

{
  "LeakDetected": 0,
  "BatteryLevel": 87,
  "LowBattery": 0,
  "StatusFault": 0,
  "PowerOn": 1
}

Map these fields with any Homebridge plugin that can poll a JSON endpoint (e.g. a leak sensor on LeakDetected, a battery service on BatteryLevel/LowBattery). Fountain commands go through POST /device/DEVICE_ID/fountain with a body like {"action": "MODE_SMART"} — but read the warning in the code first: fountain control goes through PetKit's BLE relay and may misbehave on some models.

Camera (Yumshare Solo) via go2rtc — the WHEP endpoints accept the token as a query string because go2rtc sources cannot send custom headers. In go2rtc.yaml:

streams:
  yumshare_cam:
    - webrtc:http://192.168.1.10:8787/device/DEVICE_ID/whep?token=YOUR_TOKEN#format=whep

The streaming module (agora/) is included in this repository — adapted from the MIT-licensed homeassistant_petkit integration — and its dependencies are in requirements.txt, so camera streaming works out of the box. All streaming tokens are obtained at runtime from the PetKit cloud through your own session; no static credentials are involved.

Cameras in Apple Home (field-tested recipe)

go2rtc automatically re-serves every stream over RTSP (port 8554 by default), and the verified homebridge-camera-ffmpeg plugin can expose that RTSP stream as a HomeKit camera. The full chain:

bridge (WHEP) → go2rtc (RTSP :8554) → homebridge-camera-ffmpeg → Apple Home

1. Configure the stream in go2rtc.yaml as shown above and check it plays in the go2rtc web UI (http://<host>:1984).
2. Install homebridge-camera-ffmpeg from the Homebridge UI and add a camera (via its settings form, or in config.json):

{
  "platform": "Camera-ffmpeg",
  "name": "Camera FFmpeg",
  "cameras": [
    {
      "name": "Feeder camera",
      "videoConfig": {
        "source": "-i rtsp://127.0.0.1:8554/yumshare_cam",
        "stillImageSource": "-i http://127.0.0.1:1984/api/frame.jpeg?src=yumshare_cam",
        "vcodec": "copy",
        "audio": false
      }
    }
  ]
}

Use 127.0.0.1 if Homebridge runs on the same host as go2rtc, otherwise the host's LAN IP. "vcodec": "copy" passes the H.264 stream through without transcoding (low latency, low CPU). The stillImageSource uses go2rtc's frame endpoint for tile previews.

3. Restart Homebridge. Cameras are exposed as individual accessories: add each one in the Home app (+ → Add Accessory → More options) using the pairing code shown in the Homebridge log/UI.

If the first live view stays black, retry after a few seconds: the initial request has to wake the whole chain (Home → ffmpeg → go2rtc → WHEP → PetKit cloud).

Security

• Credentials live only in the .env file, which is excluded from git. Never put secrets in bridge.py or in the compose file.
• Generate a strong BRIDGE_TOKEN (openssl rand -hex 32).
• The bridge is meant for the local network: do not expose it directly to the Internet.

Notes

• Device type names (d4h, t4, ctw3, ...) and state fields come from observing real dumps, not from official documentation: different models may require small adjustments in device_state.
• If the pypetkitapi library changes its exception structure, expired-session detection keeps working via the error-message fallback (already included).

Credits

• pypetkitapi by Jezza34000 — the PetKit cloud client this bridge is built on.
• The agora/ streaming module is adapted from homeassistant_petkit by Jezza34000 (MIT), with Agora reverse engineering originally by @mikey0000.
